M12 Ethernet Cable

m12 ethernet cable, m12 to rj45 cable, m12 to rj45 ethernet cable
FLECONN can manufacture and custom A-Coded D-Coded X-Coded 4 pin 8 pin m12 ethernet cable, m12 to rj45 cable, m12 to rj45 ethernet cable and networking cable for industry automation, robot, aviation industry, military industry, shipbuilding industry and so on.

 M12 Ethernet cable and m12 networking cable are widely used in industrial automation, robot, industrial camera, 100Mbps high speed, 1,000Mbps super speed, 10Gbps gigabit Ethernet applications. We may choose cat 5, cat5e, cat6, cat6a cable to connect with male and female m12 Ethernet connectors and rj45 plug according to the requirements of transmission rate from actual applications.

 M12 Ethernet cables are made up of one or two piecse of m12 4pin/8pin male/female Ethernet connectors, no rj45 connector or one rj45 plug on the other end of the cable, UPT, FTP, S/UTP & F/UTP, S/FTP Cat5e, Cat6, Cat6a cable with mult-strands 26AWG 24AWG copper wire conductor and 2 Pairs / 4 pairs of twisted pair wires. If the work environment of m12 Ethernect cable needs IP66, IP67, IP68 waterproof and dustproof function, we may overmold both of end of connectors and cable by injecting PVC/PUR/TPU resin. The material of cat5e, cat6, cat6a cable jacket also may be PVC/PUR/TPU.

M12 To Rj45 Cable

M12 To Rj45 Cable

P1: m12 d-coded 4 position female connector; P2: rj45 male connector; Shape: straight/straight; Terminal Connecting Method: soldering; Cable Specifications: 2x2P 24AWG+AB shielded SFTP cat5e cable, green pvc jacket, 1m
Rj45 M12 Cable

Rj45 M12 Cable

P1: m12 d-code 4 position female connector; P2: rj45 male connector; Shape: straight/straight; Terminal Connecting Method: soldering; Cable Specifications: 2x2P 24AWG+AB shielded STP cat5e cable, green pvc jacket, 1m
Rj45 To M12 Cable

Rj45 To M12 Cable

P1: m12 d-coding 4 pin female connector; P2: rj45 male connector; Shape: straight/straight; Terminal Connecting Method: soldering; Cable Specifications: 2x2P 24AWG+AB shielded STP cat5e cable, green pvc jacket, 1m
M12 X Code To Rj45 Cable

M12 X Code To Rj45 Cable

P1: m12 x-coding 8 pin female connector; P2: rj45 male connector; Shape: straight/straight; Terminal Connecting Method: soldering; Cable Specifications: 2x4P 24AWG+AB shielded SFT cat5e/SSTP SFTP cat6a cable, 1m
Ethernet M12 To Rj45 Cable

Ethernet M12 To Rj45 Cable

P1: m12 x-code 8 pin female connector; P2: rj45 male plug; Shape: straight/straight; Terminal Connecting Method: soldering; Cable Specifications: 2x4P 24AWG+AB shielded FTP cat5e/SSTP SFTP cat6a cable, 1m
M12 D Coded Cable

M12 D Coded Cable

P1: m12 d-code 4 pin female socket; P2: open end with free leads; Shape: straight; Terminal Connecting Method: soldering; Cable Specifications: 2x2P 24AWG+AB shielded SFTP cat5e cable, 5 meters
M12 4 Pin D Coded Cable

M12 4 Pin D Coded Cable

P1: m12 d-coded 4 pin female connector; P2: open end with free leads; Shape: straight; Terminal Connecting Method: soldering; Cable Specifications: 2x2P 24AWG+AB shielded SFTP cat5e cable, 5 meters
M12 RJ45 Patch Cord, M12 RJ45 Patch Cable

M12 RJ45 Patch Cord, M12 RJ45 Patch Cable

P1: m12 x-coded 8 pin female connector; P2: shielded rj45 male plug; Shape: straight/straight; Terminal Connecting Method: soldering; Cable Specifications: 2x4P 24AWG+AB shielded SFT cat5e/SSTP SFTP cat6a cable, 1m
M12 X Coded Ethernet Cable

M12 X Coded Ethernet Cable

P1: m12 x-coded 8 pin female socket; P2: rj45 male plug; Shape: straight/straight; Terminal Connecting Method: soldering; Cable Specifications: 2x4P 24AWG+AB shielded SFT cat5e/SSTP SFTP cat6a cable, 1m
M12 X Coded Cable

M12 X Coded Cable

P1: m12 x-coded 8 pin male connector; P2: m12 x-coded 8 Pin female connector; Shape: straight; Terminal Connecting Method: soldering; Cable Specifications: 2x4P 24AWG+AB shielded cat5e cable, 1m
M12 to M12 Ethernet Cable

M12 to M12 Ethernet Cable

P1: m12 d-code 4 pin connector; P2: m12 x-code 8 Pin connector; Shape: straight; Terminal Connecting Method: soldering; Cable Specifications: 2x2P 24AWG+AB shielded cat5e cable, 1m
M12 8 Pin X-coded Male to Female Cable

M12 8 Pin X-coded Male to Female Cable

Connector 1: m12 x-coded 8 pin male plug; Connector 2: m12 x-coded 8 Pin female plug; Shape: straight; Terminal Connecting Method: soldering; Cable Specifications: 2x4P 24AWG+AB shielded cat5e/cat6a cable, 1m
M12 D-Coded to M12 X-Coded Cable

M12 D-Coded to M12 X-Coded Cable

Connector 1: m12 d-coded 4 pin connector; Connector 2: m12 x-coded 8 Pin connector; Shape: straight; Terminal Connecting Method: soldering; Cable Specifications: 2x2P 24AWG+AB shielded cat5e cable, 0.5m
M12 D-Coded 4 Pin Male to M12 X-Code 8 Pin Male Connector Cable

M12 D-Coded 4 Pin Male to M12 X-Code 8 Pin Male Connector Cable

Connector 1: m12 d-coded 4 pin male plug; Connector 2: m12 x-coded 8 Pin male plug; Shape: straight; Terminal Connecting Method: soldering; Cable Specifications:2x2P 24AWG+AB shielded cat5e cable, 0.5m
